Features:

1. Fast response time ( typically less than 1.0ps from 0V to VBR min)

2. Complies with IEC61000-4-5 standard surge test

3. Uni/Bi polar two functional option

4. Common size of 3.0x1.9x1.1mm SOD-123FL package

5. 200W Peak Pulse power capability at10×1000μs waveform

Application:

Electronic products, Automotive industries, Munitions, Telecommunications, Aerospace industries, and Intelligent control systems, testing equipments of I/O Interface, AC/DC Power supply and Low frequency signal transmission line (RS232, RS485, etc.)
